Electronic Lab Equipment Universal Testing Tensile Strength Machine Price

Product Details:

Place of Origin:	China
Brand Name:	Dahometer
Certification:	ISO CE
Model Number:	WDW-1D

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	negotiable
Packaging Details:	Standard Export Wooden Case
Delivery Time:	7days
Payment Terms:	T/T, Western Union
Supply Ability:	1000 Set Per Months

Contact Now

Detailed Product Description

Name:	Universal Tensile Strength Testing Machine Price	Test Machine Level:	0.5 Class
Effective Force Range:	0.2％～100％FS	Force Accuracy:	Within ±0.5%
Maximum Test Speed:	500mm/min	Optional Maximum:	1000mm/min
High Light:	110VAC Tensile Strength Machine , 220VAC Tensile Strength Machine , 500mm/min Tensile Strength Tester

Electronic Lab Equipment Universal Testing Tensile Strength Machine Price

Advantages:

1. The structure is made of the paint-coated aluminium blanking plate. The interior is used the high-accuracy,low-resistance and zero clearance of two ball screw and oriented pole which improve loading efficiencyand structure rigidity.

2. Use Panasonic seveo motor which ensure high efficiency,steady transmission and low noise. The accuracy of speed can be controlled in 2%.

3. That Using the business computer as the main control machine plus the special testing software of our company can conduct all of testing parameter, work state, collecting data&analysis, result display and printing output.

Application Products:

>Medium strength metal

>Sintered products

>Friction material

>Rubber

>Plastic

>Film

>Fiber and thin lines

>Adhesive

>Foam material

>Tape

>Elastomer

>Connector

>Biomaterials

>Wood and paper products

>Metal foil

>Metallic line

>Oil bearing

>Ceramics

>Parts

>Fastener

>Composite materials

Electronic Lab Equipment Universal Testing Tensile Strength Machine Price 0

Standard:

ASTM, ISO, DIN, GB and other international standards.

Main Feature:

This machine is suitable for a wide range of applications
Powerful function, meet most of the mechanical properties test
Easy to operate, easy for anyone to operate
World-class AC servo motor and server for maintenance-free maintenance
Precision preloaded ball screw
Smooth operation, high reliability, sturdy and durable
Accurate measurement,certified by a third-party testing agency
High speed, low vibration, low noise servo motor drive
Multilingual application function, adapt to different countries’using
Test mode function such as tensile, flexural, compressive, flexural, adhesive, tear, peel, elongation, etc.

Has a variety of curve modes such as stress-strain,force-displacement, force-time, intensity-time
Automatic calculation of maximum force, minimum force, average force, maximum deformation, elongation, strength, etc.
Flexible capabilities of graph, datasheet, report viewing and printing.
Automatic homing function that automatically returns to the test start after the test is completed
With mechanical travel switch; emergency stop switch; over current, over voltage, under current, under voltage, leakage overload; software overload limit protection; breakpoint shutdown protection and other multiple protection devices
Optional: small deformation metal
extensometer, large deformation displacement tracker

Specification:

Brand

HongTuo

Model

WDW-D

-002

-005

-01

-02

-05

-1

-2

-5

-10

-20

-30

-50

Capacity

0.02

0.05

0.1

0.2

0.5

100

200

500

1000

2000

3000

5000

Unit switching

G,Kg,lb,N,KN

Displacement unit switching

Inch cm mm

Test machine level

0.5 class

Effective force range

0.2％～100％FS

Force accuracy

Within ±0.5%

Force decomposition

1/300 000

Force Power magnification

Full automatic shift switching

Displacement resolution

0.005mm

Displacement accuracy

Within ±0.5%

Deformation measurement range

0.2%～100%FS

Deformation indication accuracy

Within ±0.5%

Large deformation measurement range

(10～1000)mm

Large deformation resolution

0.05mm

Large deformation indication error limit

Within ±0.5%

Maximum test speed

500mm/min；optional maximum 1000mm/min

Minimum test speed

0.01mm/min

Speed accuracy

Within ±0.5%

Beam travel

Measuring height

standard

No grip testing stroke:330mm；With grip testing stroke:800mm

optional

Effective width

standard

420mm

optional

650mm

Fixture configuration

One set of tensile grip；can choose other grips

Returning method

Manual or automatic selection, automatically return after the test ends or manually return to the initial position

Stop method

1.Maximum break value automatically stop 2.Upper and lower limit safety setting stop

Safety devices

1.Mechanical limit switch protection 2.Emergency stop switch emergency brake

Overload protection

Over 10% of maximum load, automatic machine protection

Accessories

1 power cord; 1 test software program CD; 1 data cable; 1 manual; 1 certificate

Optional accessories

Anti-splash device (protective door); computer; printer; small deformation metal extensometer, large deformation displacement tracker, T-type workbench;

Power supply

220V.AC/ 50HZ; 110V.AC/60HZ

Main host size/ weight

Length*Width*Height:750mm*500mm*1650mm / around 165KG

Packing size / weight

Length*Width*Height:850mm*600mm*1800mm / around 203KG
