Guangdong Hongtuo Instrument Technology Co.,Ltd
 |
| Place of Origin: | dongguan |
| Brand Name: | QUARRZ |
| Certification: | CE, FCC |
| Model Number: | AU-120AW |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | USD399-USD1599 |
| Packaging Details: | 42 X 16 X 32cm |
| Delivery Time: | 2 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram,other |
| Supply Ability: | 300 Set/Sets per Month |
| Customized: | Yes | Power Supply: | Europe Standard AC 100V - 240V |
|---|---|---|---|
| Maximum Weight: | 120g | Density Resolution: | 0.0001 G/cm3 |
| Interface: | RS - 232 | Testing Before Delivery: | Yes |
| Concentration Resolution: | 0.01% | Warranty: | 2 Years;life-long Maintenance |
| Customer Service Provided: | Yes | Usage: | Ammonia Water Concentration Meter,Ammonium Hydroxide Density Meter |
| Minimim Weight: | 0.001g | ||
| Highlight: | density testing equipment,automatic density meter |
||
Digital Electronic Automatic Ammonia Water Concentration Meter , Ammonium Hydroxide Density Meter
Directly reading ammonia water concentration,baume Bé,specific gravity SG;Accurate measuring;Simple operation;High reliability.
This device has been researched and developed by "Quarrz",It is based on Archimedes principle;Only need 5 seconds,the concentration value can be displayed;Also the baume Bé,specific gravity SG of ammonia water can be measured as well;In accordance with GB/T11198.1-11198.15,GB/T5526,13531,15223,5009;It has been widely applicated to chemical industry.
Application:
Ammonia water manufacturer,power plant,cement plant,pharmacy industry,textile industry,printing and dyeing industry,silk,industry using ammonia water,agriculture using ammonia water,medical ammonia water,chemical industry.
Specification:
AU-300AW concentration range:0.0-33.0%,concentration resolution:0.1%;baume
resolution:0.1Bé;density resolution:0.001g/cm3
AU-120AW concentration range:0.00-33.00%,concentration resolution:0.01%;baume
resolution:0.01Bé;density resolution:0.0001g/cm3
Features:
(1) Direct reading:ammonia water concentration,baume Bé,specific gravity SG.
(2) No need to check data table;No need to input the conversion coefficient of density and concentration.
(3) No limitation of concentration range;Upto 0.00-100.00%.
(4) Concentration resolution can be upto:0.01%.
(5) Function of calculating temperature compensation coefficient automatically at any interval temperature.No need manual computation.temperature range:0~99.9℃.
(6) Manual inputting temperature coefficient is allowed.compensation range:(0.00001~9.99999)/ ℃
(7) Can measure ammonia water concentration,baume Bé,specific gravity SG at standard temperature 20℃.
(8) The displaying sequence of ammonia water,baume Bé,specific gravity SG can be set freely.
(9) Function of air buoyancy compensation;and weights volume thermal expansion coefficient compensation.
(10) Only need 50ml or less specimen.High precision,easy operation,stable and durable.
(11) Equipped with AU-20B anti-corrosivity liquids measuring accessories.
(12) Including RS-232C interface.Optional accessories AU-40A cable can connect PC.AU-40 printer can print data.
(13) Equipped with special windproof dustproof cover.convenient combination.sturdy and stable.
Measuring Procedure:
(1) Place beaker filled with specimen on testing board.deduct weight of pothook.
(2) Make standard weights hanged on the pothook and submerged into liquids to be tested totally.sulfuric acid concentration H2SO4%,baume Bé,specific gravity SG will be displayed.
Standard Accessories:
host,measurement plate,AU-20B anti-corrosivity liquid measuring assembly.tweezer,thermometer,100g weights,windproof dustproof cover,measuring support,power transformer.
AU-20B standard anti-corrosivity liquid measurement assembly:
two pcs of anti-corrosivity pothpooks,two pcs of anti-corrosivity weights,two pcs of anti-corrosivity beakers.
Optional Accessories:
AU-40 printer,AU-20B anti-corrosivity liquid measuring assembly,AU-20A standard liquid measuring assembly.AU-40A cable.
Anti-counterfeiting Announcement:
The bad and good products is intermingled on market today.Most customers had suffered a lot from the brand replacement products,shell brand products,simulation products,and transferring after-sale service products.To protect your rights,please identify seriously when choose goods.Following is the method to distinguish QUARRZ brand product.
Method one:Start up,machine will display in sequence:brand,model(such as QUARRZ,AU-300S)
Method two:After starting up,press ZERO button and B button at the same time,the machine will display in sequence:brand:model,factory number.of which information correspond to the one marked on machine.
Method three:Check security code that generate automatically by machine number.
Technical Specification:
| Brand | Quarrz | |
| Model | AU-300AW | AU-120AW |
|
Ammonia Water Concentration Resolution |
0.1% | 0.01% |
| Concentration Range | 0.0~33.0% | 0.00~33.00% |
| Baume Resolution | 0.1°Bé | 0.01°Bé |
| Baume Range | 0.1~100.0°Bé | 0.01~100.00°Bé |
| Density Resolution | 0.001 g/cm3 | 0.0001 g/cm3 |
| Density Range | 0.001—99.999g/cm3 | 0.0001—99.9999g/cm3 |
| Measuring Type | 0.0~100.0% (0.00~100.00%) | |
| Measuring Time | About 5 seconds | |
| Measuring Method | Taking samples | |
| Temperature Compensation | Standard 20℃ | |
| Other target temperature | ||
| Temperature Compensation Coefficient | Automatically calculate compensation coefficient and input | |
| Manual input | ||
| Temperature Compensation Coefficient Range | (0.00001~9.99999)/ ℃ | |
| Result displaying | Standard 20℃:Ammonia water concentration,baume Bé,specific gravity SG(Displaying sequence can be set freely) | |
|
Target temperature:Ammonia water concentration,baume Bé,specific gravity SG(Displaying sequence can be set freely) |
||
| Actual temperature:Ammonia water concentration,baume Bé,specific gravity SG(Displaying sequence can be set freely) | ||
| Measuirng Assembly | Aluminum alloy measuring shelf,Aluminum alloy measuring plate | |
| Measuring Principle | Archimedes principle | |
| Measuring Calibration/Verification Method | Distilled water calibration/Distilled water verification | |
| Data Output Method | RS-232C interfac,PC or AU-40 printer | |
| Standard Accessories |
host,measurement plate,AU-20B anti-corrosivity liquid measuring assembly.tweezer,thermometer,100g weights,windproof dustproof cover,measuring support,power transformer. AU-20B standard anti-corrosivity liquid measurement assembly: two pcs of anti-corrosivity pothpooks,two pcs of anti-corrosivity weights,two pcs of anti-corrosivity beakers. |
|
| Optional Accessories | AU-40 printer,AU-20B anti-corrosivity liquid measuring assembly,AU-20A standard liquid measuring assembly.AU-40A cable. | |
| Power Supply | AC100V~240V 50HZ/60HZ(Default as European type,or choose other type) | |
| Gross Weight/Size | 4.5kg/42.5 cm×17.5 cm×32.5cm | |
