Static And Kinetic Coefficient Friction Test Machine / Instrument For Plastic Film

Static And Kinetic Coefficient Friction Test Machine / Instrument For Plastic Film

  • Static And Kinetic Coefficient Friction Test Machine / Instrument For Plastic Film
  • Static And Kinetic Coefficient Friction Test Machine / Instrument For Plastic Film
Static And Kinetic Coefficient Friction Test Machine / Instrument For Plastic Film
Product Details:
Place of Origin: Dongguan China
Brand Name: DahoMeter
Certification: ISO,SGS
Model Number: DH-MXD-02
Payment & Shipping Terms:
Minimum Order Quantity: one set
Price: negotiable
Packaging Details: standard exported package
Delivery Time: 5 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 300 sets per month
Contact Now
Detailed Product Description
Capacity Range: 0 ~ 5N Accuracy: 0.5% Of Reading Value
Stroke: 70 Mm, 150 Mm Package: Safe
Testing Before Delivery: Yes After-sale Customer Service: Yes
High Light:

universal tensile testing machine

,

universal tensile tester



Coefficient of Friction Tester Machine / Device / Equipment / Apparatus / Instrument for Plastic Film





DH-MXD-02 Coefficient of Friction Tester is designed for static and kinetic coefficient of friction tests of plastic films, sheets, rubber, paper, PP woven bags, fabric style, metal-plastic composite strips/belts for communication cable, conveyor belts, wood, coatings, brake pads, windshield wipers, shoe materials and tires. With the material smoothness testing, users can control and adjust material quality technical indexes to meet application demands. Besides, this tester is applicable to the smoothness measurement of cosmetics, eye drop and other daily chemistry.



Professional Technology



  1. 3 test modes including static coefficient of friction test, dynamic coefficient friction test and static & dynamic coefficient of friction test are available for each specimen test.
  2. This instrument conforms to multiple standards of ISO, ASTM and GB and the user could select test methods as required
  3. Test speed could be preset and adjusted by the users as required.
  4. Sled of specific weight could be customized.
  5. The sliding plane and the sled are treated by degaussing and remanence detection which effectively reduce the system error
  6. Top quality parts and components made by world famous brands are used to ensure reliable overall product performance
  7. This instrument is controlled by micro-computer with LCD display, PVC operation panel and menu interface
  8. Professional operating software supports statistical analysis of single specimen, group specimens, superposition analysis of test curves and historical data comparison functions
  9. Equipped with RS232 port and micro printer port which is convenient to the data transmission and PC connection
  10. Support Lystem™ Lab Data Sharing System for uniform and systematic data management



Test Standards



This instrument conforms to various national and international standards: ISO 8295, ASTM D1894, TAPPI T816, GB 10006





Technical Specifications



Item Specification
Capacity Range 0 ~ 5N
Accuracy 0.5% of Reading Value
Stroke 70 mm, 150 mm
Mass of Sled 200 g (Standard)
Sled of specific weight could be customized
Test Speed 100 mm/min,150 mm/min
Test speed could be adjusted

Environment

Condition

Temperature: 23±2 °C
Humidity: 20%RH~ 70%RH
Power Supply AC 220V 50Hz

Instrument

Dimension

630 mm (L) x 360 mm (W) x 230 mm (H)
Net Weight 33 kg



Configurations



Standard Configurations Mainframe, Micro Printer, Sled of 200g
Optional Parts Professional Software, Communication Cable, Customized Sled of 500g
